The Gestalt X is the mountain biker’s drop bar bike, with reliable and simple 1x drivetrains, large tire clearance, and dropper post routing for better off road control, and on road descending stability.

Specifications

Frame

Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle

Fork

Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets

Rim

Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific, Tubeless Compatible

Hub Rear

Forged Aluminum Alloy, 142x12mm, Disc, 32H

Hub Front

Forged Aluminum Alloy, 100x12mm, Disc, 32H

Spokes Nipples

14g Black Stainless Steel

Tires

Vee Tire Co., Quikstyk, 700x45, Folding Bead, Tubeless Compatible

Derailleur Rear

SRAM Apex 1 12-Speed

Derailleur Front

-

Shift Lever

SRAM Apex 1 1x12-Speed

Crankset

SRAM Apex 1, 40T

Bottom Bracket

SRAM DUB BSA

Chain

SRAM NX

Cassette

SRAM CS-XG-1275, 10-52T

Brakes Front

SRAM Apex 1 Flat-Mount Hydraulic Disc, 160mm Rotor

Brakes Rear

SRAM Apex 1 Flat-Mount Hydraulic Disc, 160mm Rotor

Brake Levers

SRAM Apex 1 Hydraulic Disc

Handlebar

Marin Butted Alloy, Compact 16º Flared Drop

Stem

Marin 3D Forged Alloy

Grips

Marin Shock Absorbing Perforated Tape

Headset

FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”

Seatpost

TranzX YSP38J, Size S-M 70mm, Size L-XL 110mm Travel, 27.2mm

Saddle

Marin Beyond Road Concept Elite

Pedals

-

Extras

Bolt-On Thru-Axles F and R
